12 inch brushless geared wheelchair dc motor with electromagentic brake high quality for pair PEWM-02

$399.00
In stock
SKU
pewm-02
12 inch brushless geared wheelchair hub motor DC 24V 250W*2 price for one pair(including left and right side)

12 inch 12inch brushless geared wheelchair dc motor

with electromagentic brake

high quality for pair

Model:PEWM-02

Voltage:DC24V

Power Rate:250w*2

Speed:2400rpm

Ratio:23:1

Light output speed:98 ~103rpm

The starting current:<= 2.2A Max

The no-load current:<=1.1A

High voltage:0 ~ 550Vac/1ma/1sec

electromagnetic brake:3n.m 24V dc

weight of pair:nearly 12kg

Delivery time:about 7days



 Product features
* brushless motor,high efficiency,long life,maintenance-free;
* single stage gear transmission,low loss,limited driving distance is long;
* small size,light weight,suitable for various portable electric wheelchair;
* the motor speed and power users can choose;
* Pneumatic tyre*12 inches;
* users take the turn round;
WechatIMG2329

HTB13jMHJVXXXXcKXXXXq6xXFXXXl

PEWM-02B
